超微 X10SRA 官方链接：

http://www.supermicro.com.tw/products/motherboard/Xeon/C600/X10SRA.cfm

Key Features

1. Single socket R3 (LGA 2011) supports
Intel® Xeon® processor E5-2600 v3,
E5-1600 v3, and 4th gen. Core i7

2. Intel® C612 chipset

3. Up to 512GB ECC DDR4 2133MHz
    LRDIMM or 64GB ECC/non-ECC
    UDIMM (available with Core i7 only);
    8x DIMM slots

4. 4 PCI-E 3.0 x16 (run at 16/16/NA/8
or 16/8/8/8), 2 PCI-E 2.0 x1 (in x4)

5. Intel® i210-AT Dual port GbE LAN

6. 10x SATA3 (6Gbps)

7. 1x COM, 1x TPM

8. 8x USB 3.0 ports
(6 rear + 2 via header)

9. HD Audio 7.1 channel connector by
Realtek ALC1150
